Xgard IR CO2 0-2%, Aluminium, M20, ATEX
Reference: XIR-A1-01-CY
Xgard IR infrared detector of flammable gases and vapors and CO2 Main features Sensor life for more than 5 years low operating costs Easy maintenance and operation, easy sensor access and quick exchange installation flexibility does not have any specific requirements for ele
Your price
on inquiry
Availability: ask us
Product description
Product description
Xgard IR infrared detector of flammable gases and vapors and CO2
Main features
- Sensor life for more than 5 years
- low operating costs
- Easy maintenance and operation, easy sensor access and quick exchange
- installation flexibility
- does not have any specific requirements for electronics, signal distribution or power supply
- durability and reliability
- made of corrosion-resistant aluminum with the possibility of additional special covers for use in splashing and running water
- ATEX certification
**** Other gases on request
Parameters
Parameters
| Brand: | XGARD IR |
| Category: | Measurement and control / Gas measurement / Fixed detectors |
Technical specifications
| GAS | CO2 0 až 2% |
| Sensor type | IR |
| Dimensions | 156 mm x 166 mm x 111 mm |
| Weight | 1 kg |
| Ingress protection | IP65 |
| Cable entries | 1 x M20 |
| Terminations | 0.5 – 2.5 mm2 csa (20–13 awg) |
| Operating temperature | –20 až 55 °C |
| Humidity | 0–95% RH |
| Zero drift | < 2% FSD/month |
| Response time | T90 < 30 s |
| Operating voltage | 10–30 V |
| Power requirements | 50mA at 24Vdc, 67mA at 10Vdc |
| Electrical output | 3-wire 4–20 mA (current sink or source) |
| Approvals ATEX | II 2 GD Exd IIC T6 (Tamb to +50°C), II 2 GD Exd IIC T4 (Tamb to +80°C) |
Use
| Gas detected | CO2 |
Operating conditions
| ATEX | ATEX |
| Analogue output | 4-20 mA |
| Detection/Operation principle | IR |
